MIL-PRF-24236D
TABLE I. Qualification inspection.
Method
Examination or test
Requirement paragraph
paragraph
Group I (all sample units) 1/
Visual and mechanical examination
Solderability (3 sample units)
Calibration
Creepage (when applicable)
Sensitivity response
Temperature anticipation (when applicable)
Seal (as applicable)
Dielectric withstanding voltage
Insulation resistance
Contact resistance
Group II (3 sample units from group I)
Thermal shock
Terminal strength
Low level (when applicable)
Moisture resistance
Flame response (when applicable)
Short circuit
Group III (4 sample units from group I)
Minimum current (when specified)
Vibration
Shock
Group IV 1/ 2/
Overload cycling
Endurance
Group V (all sample units from groups II, III and IV)
Visual and mechanical examination
Calibration
Creepage (when applicable)
Sensitivity response
Temperature anticipation (when applicable)
Seal (as applicable)
Dielectric withstanding voltage
Insulation resistance
Contact resistance
Resistance to solvents
Group VI (4 sample units from group I)
Salt spray (corrosion)
Sand and dust (when applicable) (2 sample units)
Explosion (when applicable) (2 sample units)
1/
Total number of sample units is dependent upon the number of loads specified (see 3.1).
2/
Three sample units shall be tested at the lowest temperature at the rated ac resistive load for which
qualification is sought (see 3.1). Three sample units shall be tested at the midrange temperature at the rated
ac resistive load for which qualification is sought (see 3.1). If no ac resistive loads are specified (see 3.1), test
low and midrange temperatures at the highest specified dc load. Three sample units shall be tested at the
highest temperature for which qualification is sought at each load specified (see 3.1).
