MIL-PRF-24236 Switches, Thermostatic, \(Metallic And Bimetallic\), General Specification ForThis specification covers the general requirements for metallic-element actuated, thermostatic switches intended primarily for use in electrical and electronic equipment, in alternating current \(ac\) and direct current \(dc\) applications, where temperature protection, overheat detection, or accurate temperature control is required. The operating temperatures and operating temperature ranges of switches are covered by this specification \(see 3.1 and 6.2.2\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13

MIL-PRF-24236D

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those listed in the issue of the Department of Defense Index of Specifications and Standards (DoDISS) and

supplement thereto, cited in the solicitation (see 6.3).

FEDERAL STANDARDS

Screw-Thread Standards for Federal Services.

DEPARTMENT OF DEFENSE SPECIFICATIONS

Relays, Electrical, Hermetically Sealed, DPDT, Low Level and 2 Amperes.

Fuses; Instrument, Power, and Telephone.

(See Supplement 1 for list of applicable specification sheets.)

DEPARTMENT OF DEFENSE STANDARDS

Test Methods for Electronic and Electrical Component Parts.

Leads, Weldable, for Electronic Component Parts.

Marking of Electrical and Electronic Parts.

or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)

2.3 Non-Government publications. The following document(s) form a part of this document to the extent specified

herein. Unless otherwise specified, the issues of the documents, which are DoD adopted, are those listed in the issue

of the DoDISS cited in the solicitation. Unless otherwise specified, the issues of documents not listed in the DoDISS

are the issues of the documents cited in the solicitation (see 6.3).

AMERICAN NATIONAL STANDARDS INSTITUTE (ANSI)

General Requirements for Calibration Laboratories and Measuring and Test Equipment.

(Copies of these documents are available online at https://dod.nssn.org/search.html or from the American National

Standards Institute (ANSI), 11 West 42nd Street, New York, NY 10036-8002, telephone 212-642-4900, fax 212-302-

1286.)

INTERNATIONAL ORGANIZATION FOR STANDARDS (ISO)

Quality Assurance Requirements for Measuring Equipment - Part 1; Meteorological

Confirmation System for Measuring Equipment.

(Copies of these documents are available online at https://www.nssn.org/search.html or from the American National

Standards Institute (ANSI), 11 West 42nd Street, New York, NY 10036-8002, telephone 212-642-4900.)

SOCIETY OF AUTOMOTIVE ENGINEERS
