MIL-PRF-24236D
TABLE IV. Group B inspection.
Examination or test
Requirement paragraph
Method paragraph
Subgroup 1 (3 sample units)
Thermal shock
Terminal strength
Low level (when specified)
Moisture resistance
Flame response (when applicable)
Short circuit
Overload cycling
Subgroup 2 (3 sample units)
Vibration
Shock
Minimum current (intermediate current)
(when specified)
Endurance 1/
Subgroup 3 (3 sample units from subgroup 2)
Salt spray (corrosion)
Sand and dust (when applicable)
Explosion (2 sample units) (when
applicable)
Subgroup 4 (all sample units)
Visual and mechanical examination
Calibration
Creepage (when applicable)
Sensitivity response (when applicable)
Temperature anticipation (when applicable)
Seal (as applicable)
Dielectric withstanding voltage
Insulation resistance
Contact resistance
1/ If no ac resistive loads are specified (see 3.1), test at the highest specified dc load.
4.6 Methods of examination and test.
4.6.1 Visual and mechanical examination. Switches shall be examined to determine that the materials, design,
construction, physical dimensions, markings, and workmanship are in accordance with the applicable requirements
(see 3.1, 3.4, 3.5, 3.28, and 3.33), and when specified, switches shall be X-rayed in two planes perpendicular to its
axis to ascertain correct alignment of all internal actuating elements, the integrity of the unit, and any entrapped
foreign matter.
4.6.2 Solderability (see 3.7). Switches shall be tested in accordance with method 208 of MIL-STD-202. The
following details and exception shall apply:
(a). Number of terminations for each part to be tested - Two.
(b). Dipping device - Need not be used.
(c). Solder dip - Applicable.
(d). Examination of terminations - Method for evaluation of lugs and tabs shall apply.
