MIL-PRF-24236-1 Switches, Thermostatic, \(Bimetallic\), Subminiature, Type I, Hermetically Sealed, Single Pole, Single Throw \(Spst\), 5 Amperes, And Low Level

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13

MIL-PRF-24236/1P

.026

.016

�.640

.956

.76

MAX

.74

.924

2X FULL R

.117

.103

Configuration A6

.562�.010

ADJUSTABLE FROM

�.375 to �.875

.6460MAX

�.0 M X

Configuration A7

Weight .07 pound Maximum

FIGURE 1. Switches, thermostatic, (bimetallic), subminiature, type I, hermetically sealed - Continued.
