MIL-PRF-24236/1P
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Operating temperature range: -65�F to +500�F.
Class: Class 4, unless otherwise specified in table I, except 80,000 feet altitude.
Mounting: See tables I and II, and figure 1.
Weight: Not to exceed .025 pound unless otherwise stated.
Operating temperature and tolerances: See table I.
Electrical ratings: See table III.
Endurance test: See table III.
QUALIFICATION:
Single submission: Restricted to switch submitted.
Group submission: See table IV.
Part or Identifying Number (PIN): The PIN shall be selected either from table I which consists of M24236/1- (dash
number from table I), or if required characteristics are not contained in this table, PINs shall be assigned as
illustrated below:
M24236/1-
A
G
F
E
H
L
Specification sheet number
Configuration and contact
action (see table II)
High temperature setting to
the nearest 25�F (see table V)
High temperature setting to the nearest
5�F and its tolerance (see table VI)
Low temperature setting to
the nearest 25�F (see table V)
Low temperature setting to the nearest
5�F and its tolerance (see table VI)
Add the letter "L" when low level is required
PIN M24236/1-AGFEHL identifies a temperature switch of configuration A which opens on increasing temperature
at 65�F �5�F and closes on decreasing temperature at 25�F �5�F and has low level capabilities.
12
