INCH-POUND
MIL-PRF-24236/1P
19 November 2012
SUPERSEDING
MIL-PRF-24236/1N
14 February 2012
PERFORMANCE SPECIFICATION SHEET
SWITCHES, THERMOSTATIC, (BIMETALLIC), SUBMINIATURE, TYPE I, HERMETICALLY SEALED,
SINGLE POLE, SINGLE THROW (SPST), 5 AMPERES, AND LOW LEVEL
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and MIL-PRF-24236.
+.045
.243
-.070
.4095
.3 0
.640
Ø
..280
280
.540
.300
.230
2X Ø.071
Configuration A (see note 6)
.500
MAX
.640
.400
.395
Ø
.540
.280
0
.300
.230
RIGHT ANGLE
TERMINALS
2X Ø.071
SEE NOTE 5
Configuration B (see note 6)
FIGURE 1. Switches, thermostatic, (bimetallic), subminiature, type I, hermetically sealed.
AMSC N/A
FSC 5930
