MIL-PRF-24236/1P

.187

� .005

.540

MAX

.138-32 UNC-2A

.481

MAX

RIGHT ANGLE

TERMINALS SEE

CONFIGURATION B

Configuration B4

.587 MAX

.481

..625

625

.410

� ..010

� 005

HEX

.22

.18

281

.375

� .005

� .010

.60

� .55

.165-32 UNC-2A THD

Configuration B5

FIGURE 1. Switches, thermostatic, (bimetallic), subminiature, type I, hermetically sealed - Continued.
