MIL-PRF-22885/74J
TABLE V. Configuration.
Code
Configuration
A 1/
Complete assembly with front lens plate
{see figure 1}
B 1/
Complete assembly without front lens plate
{see figure 1}
C
Type 1
Plug-in switch/indicator assembly with front lens plate
{see figure 3}
D
Plug-in switch/indicator assembly without front lens plate
{see figure 3}
E
Housing only
F 1/
Complete assembly with front lens plate
{see figure 1}
G 1/
Complete assembly without front lens plate
{see figure 1}
Type 2
C
Plug-in switch/indicator assembly with front lens plate
{see figure 3}
D
Plug-in switch/indicator assembly without front lens plate
{see figure 3}
K
Housing only
H 1/
Complete assembly with front lens plate
{see figure 1}
J 1/
{see figure 1}
Complete assembly without front lens plate
L
Type 3
Plug-in switch/indicator assembly with front lens plate
{see figure 3}
M
Plug-in switch/indicator assembly without front lens plate
{see figure 3}
N
Housing only
P 1/
Complete assembly with front lens plate
{see figure 1}
R 1/
Complete assembly without front lens plate
{see figure 1}
L
Type 4
Plug-in switch/indicator assembly with front lens plate
{see figure 3}
M
Plug-in switch/indicator assembly without front lens plate
{see figure 3}
S
Housing only
1/ For other than direct government stocking, acquisition of assembled units may be made with the code
letters indicated. These part numbers shall not appear on the items, but may be marked on shipping
containers. The individual part numbers for plug-in switch indicator assembly and housing shall be
marked as required.
2/ Type 3 and 4 switches are not available in an alternate action configuration.
TABLE VI. Contact action. 1/
Code
Contact action (see figure 2)
A
2PDT Momentary
B
4PDT Momentary
2PDT Alternate 2/
C
4PDT Alternate 2/
D
E
Indicator function only
1/ This code is not required when specifying
housing portion of switch only.
2/ Alternate action switches are not available
in short housing configurations.
7
