MIL-PRF-22885/74J
Operating characteristics:
Actuation force: 4 pounds maximum.
Shock: Method I.
Electrical endurance: See table I for test loads.
Intermediate current: Applicable.
Illuminated chromaticity limits: See MIL-PRF-22885/82.
Luminance: See table II.
TABLE I. Electrical ratings.
Load
28 V dc
115 V ac, 60 Hz
(amperes)
(amperes)
Resistive
5.0
5.0
Inductive
2.5
2.5
Lamp
1.5
1.5
TABLE II. Luminance.
Minimum switch photometric
Color
brightness (foot lamberts)
Green (G)
15
Yellow (Y)
200
Red (R)
60
Blue (B)
5
White (W)
110
Application information:
Mounting torque (mounting screw): 4 inch-pounds maximum.
Quality assurance provisions:
Group submission: The following applies when the momentary and alternate action switches, types 1 through 4,
are submitted for qualification at the same time.
Qualification inspection: See table III.
Retention of qualification: See table IV. Table IV is applicable provided that qualification is being maintained on
similar MIL-PRF-22885/80 switches.
5
