MIL-PRF-22885/74J
Type
Dimension B
Types 1 and 2
2.960 (75.18)
Types 3 and 4
2.650 (67.31)
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerance is ±.016 (.41 mm).
3. Metric equivalents are in parentheses.
4. Metric equivalents are given for general information only.
5. Types 3 and 4 (shorter versions of types 1 and 2) are available in momentary action and indicator versions only.
FIGURE 3. Plug-in switch/indicator assembly.
3
