MIL-PRF-22885/109B

Panel Cutouts

( Cutout dimensions shown are square dimensions)

.83 MIN

.75 MIN

+.010

.755 -.000

.689 -.000

.75 MIN

.83 MIN

+.005

R .030 -.025

R .030-.025

FOR DOUBLE SLEEVE MOUNTING

FOR SINGLE SLEEVE MOUNTING

CATEGORY II II

CATEGORY

Inches

.005

0.13

.010

0.25

.025

0.64

.030

0.76

.689

17.5

.75

19.1

.755

19.2

.83

21.1

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. See figure 8 for additional applicable notes.

FIGURE 3. Switches with Pokehome connector module termination - Continued.
