MIL-PRF-22885/109B

.75

.28

.03 PANEL THICKNESS

.25

.03

.25

.03

.03 PANEL SEAL, STANDARD

1.00

1.30

MOUNTING SLEEVE

MOUNTING CAM

.17 TYP

SHORT PUSH BUTTON

TWO-POLE, 1.00 IN. BASE

HIGH EFFICIENCY

(TYPE 1)

PUSH BUTTON (TYPE 2)

TWO-POLE, 1.30 IN. BASE

(TYPE 2)

Inches

.03

0.8

.17

4.3

.25

6.4

.28

7.1

.75

19.

1.00

25.4

1.30

33.

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. Push button height dimension is measured at center of legend area.

4. See figure 8 for additional applicable notes.

FIGURE 2. Two-pole switch and indicator light - solder terminals.
