MIL-PRF-22885/103B
Weight (±10%):
Style
Ounces
Grams
I
.71
20
A
1.20
34
C
1.90
54
S
1.90
54
W
1.90
54
L
1.90
54
Operating characteristics:
Actuation force: 3.5 ±1.0 pounds (1.59 ±.45 kg)
Release force: 0.4 (.18kg) pound minimum.
Actuator travel: .20 inch (5.08 mm) nominal.
Terminal strength:
Common termination system (style C): Using crimping tool M22520/1-01 and positioner M22520/1-02 to install
connector contact on wire, and insertion/extraction tool M81969/14-02, the crimped wire contact shall be
inserted and extracted 10 times. The insertion and extraction force shall not exceed 10 pounds.
The contact shall again be inserted, and must hold axial load of 20 pounds minimum for 10 seconds.
Shock: Method I.
Electrical endurance: 25,000 cycles. See table I for test loads.
TABLE I. Electrical ratings.
Sea level and 70,000 feet
Sea level
Load
28 V dc
115 V ac
30 mV 1/
.01 Ampere
2 Amperes
2 Amperes
Resistive
1 Amperes
1 Amperes
Inductive
.75 Ampere
.75 Ampere
Lamp
1/ Maximum dc or peak ac, 50,000 cycles. Low level life test
conditions only.
Dielectric withstanding voltage:
Sea level: 1,056 V rms.
70,000 ft:
450 V rms.
Logic level life: Applicable.
