INCH-POUND
MIL-DTL-9419G
25 March 2008
SUPERSEDING
MIL-DTL-9419F
1 June 2001
DETAIL SPECIFICATION
SWITCH, TOGGLE, MOMENTARY, FOUR-POSITION ON, CENTER OFF,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers four-position, momentary on, center off, positive action switch
with free return to the off position.
1.2 Classification. Switches covered by this specification will be classified by type as indicated herein
(see 3.1).
Type I - Snap action, positive break operation.
Type II - Nonpositive break operation.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
this list, document users are cautioned that they must meet all specified requirements documents cited in
sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract.
Comments, suggestions or questions on this document should be addressed to Defense Supply Center
Since contact information can change, you may want to verify the currency of this address information
using the ASSIST Online database at https://assist.daps.dla.mil
AMSC N/A
FSC 5930
