MIL-PRF-8805/110E
PIN:
Specification
sheet number
dash number
M8805/110-
7
4
1
2
Case style
Terminal type/
Circuit
Button
Electrical rating
schematic
color
Example:
M8805/110-7412 designates a switch of case style 7, with solder termination, low level
electrical rating, that is dusttight and has a 2 terminal normally open circuit and a black
button.
TABLE IV. Qualification inspection.
Other switch
Inspection
Basic switch
Extent of approval
samples
In addition, 2 sample
Required number of
units of each of the
sample units of 3
other configurations
Qualification
terminal N.O. or 3
Required sample units
shown on this
inspection
terminal N.C.
of the 4 terminal two
specification sheet
All
table of
(groups VII and X
circuit configuration
shall be submitted to
MIL-PRF-8805
tests, qualification
visual and
inspection table,
mechanical
MIL-PRF-8805)
inspection.
Referenced Documents:
MIL-PRF-8805
MS 25082
NASM 35333
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where modifications from this revision were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations.
Custodian:
Preparing activity:
Navy - EC
DLA - CC
Air Force - 85
DLA - CC
(Project 5930-2011-114)
Review activities:
Air Force - 99
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.dla.mil/ .
