MIL-PRF-8805/110E
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2.
Enclosure design: 2 (dusttight) or 3 (watertight).
Temperature characteristic: 1 (-55° to +85°C).
Shock type: M (100 g's).
Vibration grade: 2 (10 Hz to 2,000 Hz).
Weight: .030 pound maximum.
Dielectric withstanding voltage: 1,050 V rms.
After electrical endurance: Between all terminals and mounting plate only.
Operating characteristics:
Actuating force: 27 ±8 ounces, 20 percent variation from specified values acceptable
after test.
Total travel: .080 inch maximum.
Strength of actuator: 10 pounds.
Sand and dust: Applicable.
Terminal strength: 5 pounds, all directions.
Mechanical endurance: 100,000 cycles.
Electrical endurance: 50,000 cycles. Electrical ratings, see table I.
TABLE I. Electrical ratings.
Circuit schematics 1, 2, and 6
Sea level
50,000 feet
Load
28 V dc
115 V ac, 60 Hz
28 V dc
115 V ac, 60 Hz
NO or NC
2 circuit 1/
NO or NC 2 circuit 1/
NO or NC 2 circuit 1/ NO or NC 2 circuit 1/
(amperes)
(amperes)
(amperes) (amperes)
(amperes) (amperes) (amperes) (amperes)
Resistive
5
4
5
4
5
4
5
4
Inductive
3
2
3
2
3
2
3
2
Motor
3
---
3
---
---
---
---
---
Lamp
1
---
1
---
---
---
---
---
1/ Independent loads connected to each throw.
4
