MIL-PRF-22885H
1.2.3 Vibration grade. The vibration grade is identified by a single digit in accordance with table III.
TABLE III. Vibration grade.
Frequency
Acceleration level
Symbol
range
1
10 Hz- 55 Hz
0.06 inch total excursion, method 201 of MIL-STD-202
2
10 Hz- 500 Hz
10 g peak, test condition A, method 204 of MIL-STD-202
3
10 Hz-2,000 Hz
15 g peak, test condition B, method 204 of MIL-STD-202
1.2.4 Operation. The operation of the switch is identified by a single letter in accordance with table IV.
TABLE IV. Operation.
Operation
Symbol
Momentary action
A
Alternate action
B
Push pull
C
Magnetically held
D
Position indicating, alternate action
E
Position indicating, magnetically held
F
Sequence action
G
Indicator light only
H
1.2.5 Color. The color of the lens will be identified by a single letter in accordance with table V.
TABLE V. Color.
Illuminated
Symbol
color
R
Red
G
Green
Y
Yellow
B 1/
Blue
W
White
V
Violet
O
Opaque
H
NVIS Green A
J
NVIS Green B
K
NVIS Yellow
L
NVIS Red
1/ Blue is not recommended
and should be used only
when absolutely necessary.
2
