MIL-PRF-22885H
3.45 Marking.
3.45.1 Identification of product. Switches shall be marked in accordance with MIL-STD-1285 as follows:
a.
PIN (category I only).
b.
Manufacturer's part number (category II).
c.
Manufacturer's name or trade mark.
d.
Source code (if space is available).
e.
Date code.
f.
Terminal identification (see 3.1).
g.
NVIS type and class as specified in MIL-L-85762 (when applicable).
TABLE VIII. Illuminated chromaticity limits. 1/
Color
x
y
Red
.695
.285
.703
SL 2/
.325
.655
.660
SL 2/
Green
.260
.570
.300
.630
.160
.660
.200
.720
Yellow
.562
.415
.570
SL 2/
.382
.596
.605
SL 2/
Blue
.150
.260
.220
.260
.220
.320
.150
.320
White
.400
.420
.460
.420
.400
.380
.460
.380
Violet
.480
.280
.480
.320
.530
.280
.530
.320
1/
The chromaticities of the color lenses
expressed as "x" and "y" coordinates on
the CIE chromaticity diagram shall be
within areas bounded by the coordinates
listed for each color.
2/
SL - Spectrum locus (where
intersected by other coordinate pair).
3.45.2 Terminal identification. Terminals shall be marked to indicate the contact arrangement of the switch. When
specified, terminal markings shall be augmented by a circuit schematic (see 3.1 and 6.2). There shall be no over-
marking of the terminal identification.
11
