MIL-PRF-22885/92B
TABLE VIII. Group A inspection.
Inspection
Visual and mechanical inspection 1/
Operating characteristics
Dielectric withstanding voltage
Contact resistance (switch)
1/ At the option of the contractor,
in-process inspection may be used
to meet the materials and design
and construction requirements
provided they meet the acceptable
quality level and all of the
contractor's in-process control data
on these tests are made available
to the Government upon request.
TABLE VIII. Qualification (group submission).
Inspection
Samples 4/
Extent of
approval
Group I
Visual and mechanical inspection 1/
All
Solderability 2/
Resistance to solder heat 2/
Contact resistance
Operating characteristics
Group II
Terminal strength 2/
M22885/92-BAA11W (4 samples)
Strength of actuating means 3/
All
M22885/92-FAA21FWW (2 samples)
Lamp retention
M22885/92-DAA21BWW (2 samples)
Thermal shock
Vibration
Shock (specified pulse)
Moisture resistance
Dielectric withstanding voltage
Group III
M22885/92-BAA11W (2 samples)
Salt spray (corrosion)
M22885/92-FAA21FWW (2 samples)
Group IV
M22885/92-BAA11W (2 samples)
Short circuit
M22885/92-FAA21FWW (2 samples)
Dielectric withstanding voltage
Operating characteristics
See footnotes at the end of table.
13
