MIL-PRF-22885/92B
Electrical ratings and endurance: See table III.
Operating characteristics: See table IV.
TABLE III. Electrical ratings and endurance.
Rating
Cycles
Pushbuttons
10 amperes, 125 V ac (60% power factor)
25,000
8 amperes, 28 V dc resistive
Rockers and paddles
15 amperes, 125 V ac (60% power factor)
25,000
10 amperes, 28 V dc resistive
TABLE IV. Operating characteristics.
Configuration
Characteristic
Value
Pushbutton
.170 inch min
Total actuator travel
Rocker
30 6
Paddle
30 6
Contact resistance (switch):
Initial: .100 ohms maximum.
After electrical endurance: Not applicable.
Lamp contact resistance: Lamp circuit resistance test plug in accordance with figure 6.
Strength of actuating means:
Rocker actuation - The static load shall be gradually applied to the rocker surface when that surface is parallel
to the mounting surface.
Paddle actuation - With the paddle in the extreme position, a static load of 15 pounds shall be gradually applied
perpendicular to the paddle axis and parallel to the direction of paddle travel.
Thermal shock: Temperature extremes shall be -40 C to +65 C.
Shock (specified pulse): MIL-STD-202, method 213, test condition A (50 G's).
Field of view: Obstruction of view by the paddle shall not be cause for failure.
Color and luminance: See tables V and VI.
Group A inspection: See table VII.
Qualification inspection: See table VIII.
10
