MIL-PRF-22885/86C
TABLE III. Dash numbers, design and operating characteristics - Continued.
Circuit
Lens
RF:
Dash number 1/
description
code
shielded
Type S
Type W
-082(XXXX)
-174(XXXX)
Indicator
A
No
-083(XXX)
-175(XXX)
Indicator
B
No
-084(XX)
-176(XX)
Indicator
C
No
-085(X)
-177(X)
Indicator
D
No
-086(XXX)
-178(XXX)
Indicator
E
No
-087(XX)
-179(XX)
Indicator
F
No
-088(XXX)
-180(XXX)
Indicator
G
No
-089(XXX)
-181(XXX)
Indicator
H
No
-090(XXXX)
-182(XXXX)
Indicator
A
Yes
-091(XXX)
-183(XXX)
Indicator
B
Yes
-092(XX)
-184(XX)
Indicator
C
Yes
-093(X)
-185(X)
Indicator
D
Yes
-094(XXX)
-186(XXX)
Indicator
E
Yes
-095(XX)
-187(XX)
Indicator
F
Yes
-096(XXX)
-188(XXX)
Indicator
G
Yes
-097(XXX)
-189(XXX)
Indicator
H
Yes
1/ Dash numbers shown are for units with color filters. Replace the X(s) with the desired color
symbol(s) of MIL-PRF-22885 in the position sequence shown in table I.
2/ See table I.
3/ These are plug-in switch or indicator modules that do not include lens and housing assemblies.
Type S terminal designation does not apply.
4/ Part or Identifying Number (PIN) M22885/86-001 through -005 have been superseded by
M22885/86-191 through -195 respectively. PIN's M22885/86-191 through -195 have unslotted
terminals in lieu of terminals with slotted holes. The term Part or Identifying Number (PIN) is
equivalent to the term part number which was previously used in this specification.
5/ These are housings only that do not include lens and switch modules.
6/ These are switch or indicator units that do not contain lens assemblies.
7
