MIL-PRF-22885/86C
Inches
mm
Inches
mm
.022
0.56
.67
17.0
.025
0.64
.685
17.40
.032
0.81
.73
18.5
.034
0.86
.735
18.67
.090
2.29
.870
22.10
.12
3.0
1.15
29.2
.125
3.18
1.24
31.5
.18
4.6
2.82
71.6
.21
5.3
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are .015 (0.38 mm) for three-place decimals and .03
(0.8 mm) for two-place decimals.
4. Terminals shall be permanently identified with numbers as shown in terminal location.
FIGURE 1. Pushbutton switch assembly - Continued.
2
