MIL-PRF-22885/80H
TABLE IV. Configuration.
Code
Configuration
Type 1
A
1/
Complete assembly with front lens plate
(see figure 1)
B
1/
Complete assembly without front lens plate
(see figure 1)
C
Plug-in switch or indicator assy with front lens plate
(see figure 3)
D
Plug-in switch or indicator assy without front lens plate (see figure 3)
E
1 Housing only
Type 2
F
1/
Complete assembly with front lens plate
(see figure 2)
G
1/
Complete assembly without front lens plate
(see figure 2)
H
Plug-in switch or indicator assy with front lens plate
(see figure 3)
J
Plug-in switch or indicator assy without front lens plate (see figure 3)
K
Housing only
Type 3
M
1/
Complete assembly with front lens plate
(see figure 1)
1/
N
Complete assembly without front lens plate
(see figure 1)
P
2/
Plug-in switch or indicator assy with front lens plate
(see figure 3)
2/
Q
Plug-in switch or indicator assy without front lens plate (see figure 3)
R
Housing only
1/ For other than direct government stocking, acquisition of assembled units may be
made with the code letters indicated. These part numbers shall not appear on the
items, but may be marked on shipping containers. The individual part numbers for
plug-in switch indicator assembly and housing shall be marked as required.
2/ Not for use in MIL-S-24317/8 multistation switch housings.
TABLE V. Contact action. 1/
Code
Contact action
A
2PDT Momentary (high impact shock resistant)
B
4PDT Momentary (high impact shock resistant)
C
2PDT Alternate
D
4PDT Alternate
E
Indicator function only (high impact shock resistant)
1/ This code is not required when specifying housing portion of switch only.
2/ Not available with type 3 switches.
