MIL-DTL-24317B

Inch

.005

.13

.124

3.15

.285

7.24

.045

1.14

.159

4.04

.330

8.38

.067

1.70

.181

4.60

.515

13.08

.070

1.78

.250

6.35

.625

15.88

.110

2.79

.270

6.86

NOTES:

1. Dimensions are in inches.

2. Reference MIL-DTL-6363/8-7 (T-1 � midget-flanged base lamp).

3. Reference MIL-DTL-6363/6-4 (T-1 subminiature-flanged-base lamp).

4. Unless otherwise specified, tolerance is .XXX � .001 (.03 mm).

5. Metric equivalents (to the nearest .01 mm) are given for general

information only and are based upon 1 inch = 25.4 mm.

6. Lamp retention adapters shall be of metal and shall weigh 5gm +1 �0 and

may be counterbored to achieve weight.

FIGURE 1. Lamp retention adapters.
