INCH-POUND
MIL-DTL-24317B
1 September 2010
SUPERSEDING
MIL-DTL-24317A
23 June 2004
DETAIL SPECIFICATION
SWITCHES, MULTISTATION, PUSHBUTTON,
ILLUMINATED AND NON-ILLUMINATED),
GENERAL SPECIFICATION FOR
Inactive for new design after 8 March 1999
This specification is approved for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for manually operated illuminated and
non-illuminated multistation, pushbutton switches for use in electronics and communications equipment.
1.2 Classification.
1.2.1 Type designation. The type designation is in the following form and as specified (see 6.2):
SM02
L
1
Style
Indication
Enclosure
(1.2.1.1)
(1.2.1.2)
design
(1.2.1.3)
1.2.1.1 Style. The switch style is identified by a two letter symbol "SM" followed by a two-digit number
which specifies the design and configuration covered by a single specification sheet.
1.2.1.2 Indication characteristic. Switches are designed by a single letter in accordance with table I.
TABLE I. Indication characteristic.
Indication
Symbol
characteristic
L
Illuminated
D
Non-illuminated
Comments, suggestions or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAT, Post Office Box 3990, Columbus, OH 43218-3990, or emailed to switch@dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5930
