MIL-DTL-24317B
TABLE VI. Group A inspection.
Requirement
Method
Examination or test
paragraph
paragraph
Visual and mechanical examination
3.25 and 3.26
Switch actuation and circuit configuration
TABLE VII. Zero defect sampling plan.
Minimum number of
Lot size
switches to be tested
1 - 12
All
13 - 150
13
151 - 280
20
281 - 500
29
501 - 1,200
34
1,201 - 3,200
42
3,201 - 10,000
50
10,001 - 35,000
60
TABLE VIII. Group B inspection.
Requirement
Method
Examination or test
Paragraph
paragraph
Dielectric withstanding voltage
Contact resistance
Seal (when applicable)
4.8 Methods of examination and test.
4.8.1 Visual and mechanical examination. Switches, lenses, color filters, panel seals and barriers shall
be examined to determine that the material, design, construction, physical dimensions, marking, and
workmanship are in accordance with the applicable requirements. (See 3.1, 3.3, 3.4, 3.25, and 3.26.)
4.8.2 Solderability (see 3.5). Switches shall be tested in accordance with method 208 of MIL-STD-202.
The following details and exception shall apply:
(a) Number of terminations of each switch to be tested Five.
(b) Dipping machine Need not be used.
(c) Solder dip Not applicable.
(d) Examination of terminations Method for evaluation of lugs and tabs shall apply.
4.8.3 Switch actuation and circuit configuration (see 3.6). The actuation and circuit configuration of the
switch shall be tested by use of test circuits for compliance with the specified functions.
14
