MIL-PRF-8805/98E
TABLE V. Lever action and circuitry.
Basic switch numbers
With toggle lever in position
Type
Keying side
Center
Opposite keying side
For
For
For
number
Toggle
Circuit
Toggle
Circuit
Toggle
Circuit
4 pole
6 Pole
8 pole
action
closed
action
closed
action
closed
1-2
1-2-3
1-2-3-4
C-NC
C-NC
C-NO
1
Maintain
Maintain
Maintain
3-4
4-5-6
5-6-7-8
C-NO
C-NC
C-NC
1-2
1-2-3
1-2-3-4
C-NC
C-NO
3
Maintain
(None)
Maintain
3-4
4-5-6
5-6-7-8
C-NO
C-NC
1-2
1-2-3
1-2-3-4
C-NC
C-NC
C-NO
5
Momentary
Maintain
Maintain
3-4
4-5-6
5-6-7-8
C-NO
C-NC
C-NC
1-2
1-2-3
1-2-3-4
C-NC
C-NC
C-NO
7
Momentary
Maintain
Momentary
3-4
4-5-6
5-6-7-8
C-NO
C-NC
C-NC
1-2
1-2-3
1-2-3-4
C-NC
C-NO
8
Momentary
(None)
Maintain
3-4
4-5-6
5-6-7-8
C-NO
C-NC
1-2
C-NC
C-NO
C-NC
9 1/
N/A
N/A
Momentary
Momentary
Maintain
3-4
C-NO
C-NC
C-NC
1/ Inactive for new design.
Reference Documents
MIL-PRF-8805
MIL-PRF-8805/4
MIL-DTL-83731
MIL-STD-202
The margins of this specification are marked with vertical lines to indicate where modifications from this
revision were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate
the requirements of this document based on the entire content irrespective of the marginal notations.
Custodians:
Preparing activity:
Navy - EC
DLA - CC
Air Force - 85
DLA - CC
(Project 5930-2009-023)
Review activities
Navy - AS
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil/ .
8
