MIL-PRF-8805/26J
TABLE I I . Qualification inspection (group submission).
Basic switch
Additional sample units
Extent of
Examination or test
assembly
for combined submission
approval
(2 sample units each)
M8805/26-002
Group I
M8805/26-003
(12 sample
Visual and mechanical examination
M8805/26-012
units)
Operating characteristics
(tested to group I only)
Group II
Strength of actuating means 1/
Strength of mounting bushing 1/
Thermal shock
(4 sample units
Vibration
_________
from group I)
Shock
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Group III
(2 sample
Salt spray (corrosion)
units from
_________
All
Visual and mechanical examination
group I)
Group IV
Low temperature operation
(2 sample units only)
Mechanical endurance at low
temperature (2 units) 2/
(4 sample units
_________
Mechanical endurance at high
from group I)
temperature (2 units)
Operating characteristics
Dielectric withstanding voltage
Visual and mechanical examination
Group V
(2 sample
Electrical endurance
units from
_________
Inductive load, dc
group I)
1/ Two sample units only.
2/ Same sample units as for low temperature operation.
5
