MIL-PRF-8805/26J
Dielectric withstanding voltage:
Sea level: 1,000 Vrms.
Altitude: 50,000 feet 400 Vrms.
In qualification inspection table after electrical endurance the dielectric withstanding voltage points
of application between all unconnected terminals of the same pole is not applicable.
Mechanical endurance: 100,000 cycles.
Electrical endurance: 25,000 cycles.
Electrical ratings: See table I.
Qualification inspection (group submission): See table II.
Part or Identifying Number (PIN): See table III.
Circuit configuration: See table IV.
TABLE I . Electrical ratings.
Sea level
50,000 feet
Load
28 Vdc
115 Vac
28 Vdc
(amperes)
(amperes)
(amperes)
Resistive
5
5
5
Inductive
3
5
2.5
Lamp
2.4
1.5
2.4
4
