MIL-PRF-8805/2K
Table V. Qualification inspection (group submission).- Continued.
Extent of
Inspection
Sample
approval
Group VII
MS25085-1, -2, or 6
Overload cycling
(18 samples)
Electrical endurance
MS25085-7,-8, or 9
Dielectric withstanding voltage
(8 samples)
Contact resistance
MS25085-10, -11, or 12
Operating characteristics
(8 samples)
MS25085-13 (10 samples)
All
Group X
MS25085-7,-8, or 9
Low level circuit
(2 samples)
Operating characteristics
MS25085-10, -11, or 12
(2 samples)
Electronic logic circuit
MS25085-7,-8, or 9
Operating characteristics
(2 samples)
MS25085-10, -11, or 12
(2 samples)
1/ Two samples for physical dimensions.
2/ Four samples of each applicable terminal type.
3/ Two samples minimum of each terminal type submitted for qualification shall be subjected to group II
test.
4/ Short circuit test shall be conducted at 28 V dc, 60 amperes.
