MIL-PRF-8805/2K
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Enclosure design: 1 (unsealed).
Temperature characteristic:
MS25085-1 through 12: 1 (-55°C to +85°C).
MS25085-13: 2 (-65°C to + 125°C).
Shock type:
MS25085-1 through 12: M(100 g's).
MS25085-13: 75 g, test condition H, method 213 of MIL-STD-202.
Vibration grade: 1 (10 to 500 Hz sinusoidal, 10 g's).
Weight: 0.006 pound maximum.
Part or Identifying Number (PIN): See table VI.
Operating characteristics: See table 1.
TABLE I. Operating characteristics .
Actuating
Pretravel
Releasing
Movement
Overtravel
PIN
force
force
differential
ounces max.
inch max.
ounces min.
inch max.
inch min.
MS25085-1
5
0.030
1
0.004
0.005
MS25085-2
5
0.030
1
0.004
0.005
MS25085-6
5
0.030
1
0.004
0.005
MS25085-7
5
0.020
1
0.004
0.005
MS25085-8
5
0.020
1
0.004
0.005
MS25085-9
5
0.020
1
0.004
0.005
MS25085-10
5
0.020
1
0.004
0.003
MS25085-11
5
0.020
1
0.004
0.003
MS25085-12
5
0.020
1
0.004
0.003
MS25085-13
2.38
0.020
.875
0.0004
0.005
Strength of actuating means:
MS25085-1 through 12: 25 pounds.
MS25085-13: 10 pounds.
Terminal strength:
Solder lug (SL): 20 pounds.
Single turret (ST) and double turret (DT): 5 pounds.
Material:
Plunger: May be glass filled nylon.
3
