MIL-PRF-8805/100G
TABLE III. Qualification and group - C tests (group submission).
Examination or test
Samples
Extent of approval
Qualification inspection table
M8805/100-017
of MIL-PRF-8805 1/ 4/
(32 units)
Visual and mechanical examination
M8805/100-016
Dielectric withstanding voltage
(2 units)
Operating characteristics
All
Visual and mechanical examination
M8805/100-012
Temperature cycling 2/
(2 units)
(in accordance with table I)
M8805/100-017
Marking test 3/
(2 units)
1/ Case and plunger grounding test to be accomplished before and after mechanical endurance.
2/ Applicable in qualification testing only.
3/ Following immersion, the switch shall also be subjected to terminal strength, insulation resistance,
dielectric withstanding voltage, operating characteristics, and seal tests.
4/ Group C: Explosion test not applicable.
TABLE IV. Dash numbers and configuration.
Dash numbers
36 +2 inch
1/
72 +2 inch
Actuator
Lead wires
-0
-0
load wires
load wires
-001
---
Pin plunger
Six wire leads brought out in
single row.
-002
-011
Pin plunger
Six wire leads brought out in two
rows of three leads each.
-003
-012
Pin plunger
Six wire leads brought out from
the bottom of the switch.
-004
---
Roller plunger
Six wire leads brought out in
single row.
-005
-013
Roller plunger
Six wire leads brought out in two
rows of three leads each.
-006
-014
Roller plunger
Six wire leads brought out from
the bottom of the switch.
-007
-015
Pin plunger
Twelve wire leads brought out in
two rows of six each.
-008
-016
Pin plunger
Twelve wire leads brought out
from bottom of switch.
-009
-017
Roller plunger
Twelve wire leads brought out in
two rows of six each.
-010
-018
Roller plunger
Twelve wire leads brought out
from bottom of switch
1/ Inactive for new design. Use dash numbers -011 thru -018.
7
