MIL-PRF-8805/100G
Marking: Marking shall remain legible after the following test:
a. Soak for a minimum of 72 hours at room temperature in each of the fluids specified below.
b. After each soak period the specimen shall be wiped dry and then rubbed with a dry thumb a
minimum of 20 times applying moderate pressure. NOTE: Each test specimen shall be
subjected to soak periods in all the fluids.
c.
If metal foil identification plates are used, they shall comply with MIL-P-19834. In addition to
the legibility requirement defined herein, the identification plate shall not become loosened or
partially or completely detached from the switch housing during or after the soak tests.
d. The test fluids to be used shall include: MIL-DTL-83133, Turbine Fuel; MIL-PRF-5606,
Hydraulic Fluid, Petroleum Base, Aircraft, Missile, and Ordnance; MIL-PRF-7808, Lubricating
Oil, Aircraft Turbine Engine, Synthetic Base.
Part numbers: M8805/100 - (dash number from table IV).
TABLE II. Electrical ratings.
Sea level 28 V dc
80,000 ft. 28 V dc
Load
-001 thru -006
-007 thru -010
-001 thru -006
-007 thru 010
and -011 thru -014 and -015 thru -018
and -011 thru -014 and -015 thru 018
(amperes)
(amperes)
(amperes)
(amperes)
Resistive
10
7
10
7
Inductive
4
2
4
2
Motor
6
4
6
4
Lamp
3
2
2
1
Qualification and group C retention of qualification:
Group submission: See table III.
Group A inspection:
Seal test: Only watertight test shall be performed in group A.
6
