MIL-PRF-22885/91C
STRIP MOUNTING
Station
1
2
3
4
5
6
7
8
9
10
11
12
X Square
.750
1.570
2.370
3.170
3.970
4.770
5.570
6.370
7.170 7.970 8.770 9.570
.005
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
X Rec-
1.141
2.370
3.570
4.770
5.970
7.170
8.370
9.570
10.770 11.970 13.170 14.370
tangular
.005
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
Y Rec-
.750
1.570
2.370
3.170
3.970
4.770
5.570
6.370
7.170 7.970 8.770 9.570
tangular
.005
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
.010
X = .750 .005
Y = 1.141 .005
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Metric equivalents are in parentheses.
4. See application information for strip mounting information.
FIGURE 5. Panel cutouts.
8
