MIL-PRF-22885/89C
Code
Basic switch
Circuit
A
MS24547-1
SPDT
B
MS24547-1
DPDT
C
MS24547-2
SPDT
D
MS24547-2
DPDT
E 1/
None
---
1/ Use code E to specify lens portion of
switch only.
TABLE V. Lens style.
Lens style
Code
(see figure 2)
A
A
B
B
C
C
D
D
Z 1/
None
1/ Use code Z to specify switch
body only (less lens).
Qualification inspection: All applicants for qualification approval shall demonstrate that each of their items
conforms to all of the requirements specified in the applicable documents singularly and in combination with all
other previously qualified items, regardless of manufacturer.
Group submission:
a.
When the basic sensitive switches are qualified to MIL-PRF-8805/4, switches shall be tested in accordance
with table VI.
b.
When the basic sensitive switches are not qualified to MIL-PRF-8805/4, the switch type for which
qualification is sought, shall be subjected to the complete tests in accordance with table X of MIL-PRF-
22885.
Group B inspection: Not applicable.
6
