MIL-PRF-22885/83E
1/ Dash numbers 01 through 06 (switches without legends) from MIL-PRF-22885/83B have been
replaced by A1W through F1W, respectively.
2/ Areas marked CLR will illuminate green when activated.
Areas marked SEC will illuminate red when activated.
All other areas will illuminate with when activated.
3/ Visible letters on a black opaque background. Letters show color when illuminated.
4/ These dash numbers are for switches with switch guards.
5/ These dash numbers are for nonilluminated switches (lamp terminals are not supplied).
6/ Terminal C is common for lamps 2 and 3 and terminal D is common for lamps 1 and 4.
7/ Luminance value is 15 5 foot lamberts.
8/ Areas marked R will illuminate green when activated. Areas marked E will illuminate yellow when
activated. All other areas will illuminate white when activated.
9/ Area marked 'BITE ON' illuminates white when activated. Area marked 'FAULT' illuminates red when
activated.
10/ Hidden legend on black opaque background. Letters show color when illuminated. 'SAFE' illuminates
yellow when activated. 'NORM' illuminates green when activated.
11/ Area marked 'ON' illuminates green when activated. Area marked 'OFF' illuminates white when
activated.
12/ Area marked 'ALERT' illuminates yellow when activated. Area marked 'CALL' illuminates white when
activated.
13/ Shall be 150 foot lamberts luminance minimum and shall be readable in 10,000 foot candles ambient.
Hidden legend on black opaque background.
