MIL-PRF-22885/67J
Part numbers: Part numbers are assigned as illustrated below. Part numbers do not include legend description.
Acquire switches with legends as category II items in accordance with MIL-PRF-22885.
M22885/67
-
018
RG
Specification
Dash number
Color codes (from table V)
sheet number
from table VII
for each lens segment,
as required. Color code
sequence is same as lens
segment sequence shown on
figure 2 below 1/
Example -
3PDT momentary action
Segment number 2 is
switch with lens
red. Segment number
configuration 1 (horiz.
3 is green.
split), silver contacts,
display type W, no EMI/RFI
shielding, retained
pushbutton.
FIGURE 2. Lens configuration and segment numbers.
1/ Part number constructed as shown replace and are interchangeable with previous part numbers which included
segment numbers in addition to color codes (example: M22885/67-018-2R3G).
9
