MIL-PRF-22885/67J
REQUIREMENTS
Design and construction. See figure 1. Basic switches shall be MIL-PRF-8805/4 (MS24547-1 or -6) or
MIL-PRF-8805/109 (M8805/109 (M8805/109-01 or -03) listed in QPL-8805.
Enclosure design: 1 (unsealed).
Temperature characteristic: 1 (-55°C to +85°C).
Vibration grade: 2 (10-500 Hz).
Operation: A (Momentary action), B (Alternate action), H (Indicator light).
Illuminated color.
Display type W (White background) - See table I.
Display type S (Sunlight readable) - See table II.
TABLE I. Illuminated color - display type W.
Chromatically coordinates 1/
2200° kelvin
Colors
X
Y
Green
.312
.685
.312
.630
.185
.630
.265
.720
Yellow
.530
.442
.544
SL 2/
.571
.402
.584
SL 2/
Red
.680
.300
.690
.310
.715
.265
.725
.275
Blue
.200
.260
.120
.220
.085
.280
.175
.315
White
.484 Ref.
.415 Ref.
X is not less than .350.
Y is not greater than .470.
Y - Y0 or Y0 - Y is not numerically greater than 0.03X.
(Y0 is the Y coordinate of the Planckian radiator for a given X).
1/ The chromaticities of the diffusing lenses or colored filters expressed as
X and Y coordinates on the CIE chromaticity diagram shall lie within areas
bounded by the coordinates listed for each color, using a source illuminate
of 2200° K.
2/ SL = spectrum locus (where intersected by other of coordinate pair).
