MIL-PRF-22885/18K
TABLE I. Dash numbers for switch housings.
Dash numbers
Circuit
Pushbutton
Operation
characteristic
lens type
Printed circuit
Solder
terminals 1/
terminals 1/
149
01
DPDT
Momentary
Threaded
150
02
DPDT
Alternate action
Threaded
151
03
Two circuit
Momentary
Threaded
152
04
Two circuit
Alternate action
Threaded
153
05
DPDT
Momentary
Snap-in
154
06
DPDT
Alternate action
Snap-in
155
07
Two circuit
Momentary
Snap-in
156
08
Two circuit
Alternate action
Snap-in
1/ These are switch housings that do not include pushbutton lens. Acquire pushbutton lens separately.
See MIL-PRF-22885/99.
TABLE II. Inactive for new design dash numbers. 1/
Dash numbers
Lens
Circuit
Operation
Lens type
Printed circuit
Solder
M22885/
characteristic
terminals
terminals
157 2/
09 2/
22-01 (Yellow)
DPDT
Momentary
Threaded
158 2/
10 2/
22-02 (White)
DPDT
Momentary
Threaded
159 2/
11 2/
22-03 (Red)
DPDT
Momentary
Threaded
160 2/
12 2/
22-04 (Green)
DPDT
Momentary
Threaded
161 2/
13 2/
22-05 (Blue)
DPDT
Momentary
Threaded
162
14
22-06 (Yellow)
DPDT
Momentary
Threaded
163
15
22-07 (White)
DPDT
Momentary
Threaded
164
16
22-08 (Red)
DPDT
Momentary
Threaded
165
17
22-09 (Green)
DPDT
Momentary
Threaded
166
18
22-10 (Blue)
DPDT
Momentary
Threaded
167
19
22-11 (Yellow)
DPDT
Momentary
Threaded
168
20
22-12 (White)
DPDT
Momentary
Threaded
169
21
22-13 (Red)
DPDT
Momentary
Threaded
170
22
22-14 (Green)
DPDT
Momentary
Threaded
171
23
22-15 (Blue)
DPDT
Momentary
Threaded
172
24
22-16 (Yellow)
DPDT
Momentary
Threaded
173
25
22-17 (White)
DPDT
Momentary
Threaded
174
26
22-18 (Red)
DPDT
Momentary
Threaded
175
27
22-19 (Green)
DPDT
Momentary
Threaded
176
28
22-20 (Blue)
DPDT
Momentary
Threaded
177 2/
29 2/
22-01 (Yellow)
DPDT
Alternate action
Threaded
178 2/
30 2/
22-02 (White)
DPDT
Alternate action
Threaded
179 2/
31 2/
22-03 (Red)
DPDT
Alternate action
Threaded
180 2/
32 2/
22-04 (Green)
DPDT
Alternate action
Threaded
181 2/
33 2/
22-05 (Blue)
DPDT
Alternate action
Threaded
