MIL-PRF-22885/105C
Dielectric withstanding voltage:
Sea level: 1,056 V rms.
70,000 ft: 450 V rms.
Logic level life: Applicable.
Terminal identification: Circuit schematic shall be marked. Identification of terminals on style C modules not
required.
Part number: See table II.
Qualification and periodic inspection: Required as a part of MIL-PRF-22885/103 or MIL-S-24317/12 switch
assemblies.
TABLE III. Part numbers.
Part number
Style
Termination 1/
Operation
Switch circuit
Lamp CKT 2/
M22885/105-
001
I
Solder
Indicator
N/A
CLG
002
I
Solder
Indicator
N/A
SLG
003
S
Solder or wire wrap
Indicator
N/A
CLG
004
S
Solder or wire wrap
Indicator
N/A
SLG
005
C
Crimp pin
Indicator
N/A
CLG
006
C
Crimp pin
Indicator
N/A
SLG
007
S
Solder or wire wrap
Momentary
4PDT
CLG
008
S
Solder or wire wrap
Momentary
4PDT
SLG
009
S
Solder or wire wrap
Momentary
2PDT
CLG
010
S
Solder or wire wrap
Momentary
2PDT
SLG
011
S
Solder or wire wrap
Alternate
4PDT
CLG
012
S
Solder or wire wrap
Alternate
4PDT
SLG
013
S
Solder or wire wrap
Alternate
2PDT
CLG
014
S
Solder or wire wrap
Alternate
2PDT
SLG
015
C
Crimp pin
Momentary
4PDT
CLG
016
C
Crimp pin
Momentary
4PDT
SLG
017
C
Crimp pin
Momentary
2PDT
CLG
018
C
Crimp pin
Momentary
2PDT
SLG
019
C
Crimp pin
Alternate
4PDT
CLG
020
C
Crimp pin
Alternate
4PDT
SLG
021
C
Crimp pin
Alternate
2PDT
CLG
022
C
Crimp pin
Alternate
2PDT
SLG
1/ Style I modules mount in style I multistation housings in accordance with MIL-24317/12. Style S modules
mate with styles S, W or L individual or multistation housings in accordance with MIL-PRF-22885/103 and
MIL-S-24317/12. Style C modules mate with style C individual or multistation housings in accordance with
MIL-PRF-22885/103 and MIL-S-24317/12.
2/ CLG = Common lamp ground. SLG = Split lamp ground.
5
