MIL-PRF-22885/105C
REQUIREMENTS:
Design and construction: See figure 1.
Intended use: Mates with sunlight readable pushbutton in accordance with MIL-PRF-22885/104. Styles S and C
mate with individual or multistation switch housings in accordance with MIL-PRF-22885/103 and MIL-S-24317/12.
Style I modules mount in MIL-S-24317/12 multistation housings only. Styles S and C are designed to be replaced
from front of panel without disconnecting behind the panel wiring. Style I requires access to behind the panel
mounting screw and removal of wiring. Style C terminals mate with M39029/1-101 connector contacts.
Classification:
Enclosure design: 1 (Unsealed).
Temperature characteristic: 1(-55°C to +85°C).
Vibration grade: 3(10 - 2,000 Hz, 15 g peak).
Operation:
A (Momentary action).
B (Alternate action).
H (Indicator only).
Material:
Common termination system (applicable to style C):
Weight (±10%):
Style I: .0176 pound.
Styles C and S: .032 pound.
Operating characteristics: In accordance with MIL-PRF-22885/103 and MIL-S-24317/12.
Electrical endurance: 25,000 cycles. See table I for test loads.
TABLE I. Electrical ratings.
Load
Sea level and 70,000 ft.
28 V dc
115 V ac
Resistive
2 Amperes
2 Amperes
Inductive
1 Ampere
1 Ampere
Lamp
.75 Ampere
.75 Ampere
4
