MIL-PRF-22885-101 Switch, Pushbutton, Illuminated, 4-Lamp, Spdt And Dpdt, 5.0 Amperes Silver Contacts, 1 Ampere Max. Gold Contacts, Dripproof, Sunlight Readable, Emi/Rfi Shielded, Nvis Compatible

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-22885/101E
TABLE I. Electrical ratings - silver contacts.
Sea level, 28 V dc
70,000 feet, 28 V dc
Load
NO or NC
NO or NC
(amperes, max)
(amperes, max)
Resistive
5.0
5.0
Inductive
3.0
2.0
Lamp
1.0
1.0
TABLE II. Electrical ratings - gold plated contacts. 1/
Load
Sea level, 28 V dc
70,000 feet, 28 V dc
(amperes, max)
(amperes, max)
Resistive
1
0.5
Inductive
0.5
0.5
1/ Low level life requirements also are applicable.
