MIL-PRF-22885/101E
Short version:
M22885/101-
007
S
2GR
(Inactive for new design)
Extended version:
M22885/101E
007
S
2GR
Specification
Switch
Display type
Display
number
configuration
(see table VI)
configuration
(see table V)
(see table VII)
Momentary action Sunlight readable
Display code 2:
switch with
display
Horiz. split,
silver contacts,
top half green,
solder termination,
bottom half red
lamp circuit 1
These PIN's do not include lamps or legends. Switches with legend information shall be acquired through Defense
Supply Center Columbus (CAGE 037Z3) drawing 90020.
Configuration dash numbers for switches with plug-in terminations, -113 through -168, have been canceled; and
configuration dash numbers for switches with PCB pin terminations, -001, -002, -005, -006, -009, -010, -013, -014,
-017, -018, -021, -023, -025, -027, -029, -030, -033, -034, -037, -038, -041, -042, -045, -046, -049, -051, -053, -055,
-057, -058, -061, -062, -065, -066, -069, -070, -073, -074, -077, -079, -081, -083, -085, -086, -089, -090, -093, -094,
-097, -098, -101, -102, -105, -107, -109, and -111, have been canceled. Switches with plug-in and printed circuit
board (PCB) mount pin terminations are considered category II parts and shall be acquired from a source listed on
QPL-22885 for MIL-PRF-22885/101. Category II PCB mount switches may not be interchangeable between
manufacturers due to variations in pin location.
Spare parts PIN: PIN's for mounting sleeve, panel spacer, panel seal, and switch housing (without pushbutton) are
listed in tables VIII and IX, and are inactive for new design.
TABLE V. Switch configuration dash number.
10
