MIL-PRF-22710/17J
COMMON "C"
NO. 13
DIAL
DIAL
CONNECTED TO
READS
POS
1
2
4
8
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are I parentheses.
3. Metric equivalents are given for general information only.
FIGURE 3. Terminal design and circuit configuration - Continued.
REQUIREMENTS
Dimensions and configuration: See figures 1, 2 and 3.
Construction: D.
Angle of throw: 36 or 45 .
Temperature-life characteristic: B. For lighted switches, the maximum temperature is 71 C.
Vibration grade: 3 (15g, 10 - 20,000 Hz).
Shock type: M (100g) and H (high-impact). Methods I and II are applicable.
Moisture resistance: Method II of MIL-PRF-22710, except that test condition A, method 103 of MIL-
STD-202 shall apply.
Altitude rating: C (0 - 70,000 feet).
Terminal design: See figure 3.
Weight: 0.5 ounce maximum.
Color (readout characters): White on black background.
