MIL-PRF-22710/17J
TABLE I. Electrical test loads.
Test or condition
Resistive
At atmospheric pressure
0.125 A
28 V dc and ac, 60 Hz
At reduced barometric pressure
0.125 A
28 V dc and ac, 60 Hz
Life (low level)
0.10 mA
30 mV
Luminace Applies only to illuminated switches (see table III).
TABLE II Photometric brightnesss.
Rating
Switch
Lamp
Brightness
filter
Volts
Ampere
Clear
5
0.115
2.0
1.0 foot-lamberts
M6363/6 or
equivalent
Red
5
0.115
1.0
0.5 foot-lamberts
Operating force (push force required to advance from one detented position to the next):
30 ounces, minimum
60 ounces maximum.
Seal: Method II, or method I and method II, as applicable (see table III).
Dielectric withstanding voltage:
750 volts rms at atmospheric pressure.
250volts rms at reduced barometric pressure, test condition C.
Sand and dust: See table III.
Explosion: Applicable.
Acceleration: Applicable.
Life (rotational): Method 206, test condition G, MIL-STD-202 (50,000 cycles - one cycle equals 720
rotation of the indicator wheel which is 16 or 20 depressions of the push button).
EMI/RFI shielding: Applicable when specified. See table III.
Military part number: See table III.
