MIL-PRF-22710/15H
MODULE A, A1, A2, A3, A4, or A5
MODULE B, B1, B2, B3, B4, or B5
TRUTH TABLE
LEAD
COLOR
(Circuit configuration1)
C
WHT/BRN
36 INDEXING
O
BLACK
DIAL
COMMON C
1
BROWN
MARKING
CONN. TO:
2
RED
0
0
3
ORANGE
1
1
4
YELLOW
2
2
5
GREEN
3
3
6
BLUE
4
4
7
VIOLET
5
5
8
GREY
6
6
9
WHITE
7
7
8
8
9
9
FIGURE 3. Module and circuit configuration.
