MIL-PRF-22710/15H
Number of
Dimensions
stations
B
C
D
A
.03 (0.76)
1
1.26
( 32.00)
1.090
( 27.69)
0.900
( 22.86)
0.920
( 23.37)
2
1.76
( 44.70)
1.590
( 40.39)
1.400
( 35.56)
1.420
( 36.07)
3
2.26
( 57.40)
2.090
( 53.09)
1.900
( 48.26)
1.920
( 48.77)
4
2.76
( 70.10)
2.590
( 65.79)
2.400
( 60.96)
2.420
( 61.47)
5
3.26
( 82.80)
3.090
( 78.49)
2.900
( 73.66)
2.920
( 74.17)
6
3.76
( 95.50)
3.590
( 91.19)
3.400
( 86.36)
3.420
( 86.87)
7
4.26
(108.20)
4.090
(103.89)
3.900
( 99.06)
3.920
( 99.57)
8
4.76
(120.90)
4.590
(116.59)
4.400
(111.76)
4.420
(112.27)
9
5.26
(133.60)
5.090
(129.29)
4.900
(124.46)
4.920
(124.97)
10
5.76
(146.30)
5.590
(141.99)
5.400
(137.16)
5.420
(137.67)
NOTES:
1. Dimensions are in inches.
2. Millimeters are in parentheses.
3. Metric equivalents are given for general information only and are based upon
1 inch = 25.4 mm.
4. Unless otherwise specified, tolerance is 0.010 (0.25).
5. Applicable to illuminated switches only. Allowance for lighting terminals for externally
replaceable lamps, when internal lighting is specified.
FIGURE 1. Style SRPC15 switch and panel cutout (unshielded switch) - Continued.
