MIL-DTL-9395/5E
TABLE III. Codes for pressure settings to
within 25 lbf/in2 and tolerances.
Unit
Tolerance
(lbf/in2)
0
+25
+50
+75
±25
Code ------------
A
B
C
D
±50
Code ------------
E
F
G
H
±75
Code ------------
J
K
L
M
±100
Code ------------
N
P
Q
R
±150
Code ------------
S
T
U
V
±200
Code ------------
W
X
Y
Z
±300
Code ------------
1
2
3
4
±400
Code ------------
5
6
7
8
Code ------------
9
0
I
-
Min or Max
TABLE IV. Codes for differential pressure settings.
Pressure
Pressure
Code
Code
(lbf/in2)
(lbf/in2)
A ----------------
0
M ----------------
275
B ----------------
25
N ----------------
300
C ----------------
50
P ----------------
325
D ----------------
75
Q ----------------
350
E ----------------
100
R ----------------
375
F ----------------
125
S ----------------
400
G ----------------
150
T-----------------
425
H ----------------
175
U ----------------
450
J -----------------
200
V ----------------
475
K ----------------
225
W----------------
500
L-----------------
250
TABLE V. Extent of qualification.
Qualifies
Part
Number of
Tests
number
samples required
M9395/5-AADAA
1 each inductive
Complete per
-AADAA
1 each resistive
qualification inspection
ALL
-A4ZXV
1 each inductive
inspection of
configurations
-A4ZXV
1 each resistive
MIL-DTL-9395
SUPERSESSION DATA: Part number M9395/5-01 is superseded by part number M9395/5-AJEF-.
NOTES:
1. Design limitations (actuation values and tolerances, deadband and deactuations values and
tolerances) should be coordinated with manufacturer(s) listed on the QPL for this specification
sheet before specifying a particular "M" number. The fact that operating characteristics can be
coded does not necessarily mean that is can be manufactured or acquired.
