MIL-DTL-9395/39D
Acceleration: C (8 G).
Pulsation amplitude: A (0 percent).
Pulsation frequency: A (0 Hz).
2
Pressure rise: A (less than 100 lbf/in ).
Dielectric withstanding voltage (at reduced barometric pressure): Applicable at 350 V rms.
Electrical connector torque: 8 foot-pounds.
Pressure port torque: 15 foot-pounds.
Terminal strength: Applicable when terminals are used.
Flame test: Applicable.
Explosion: Applicable.
QUALIFICATION:
Single submission: Restricted to switch submitted.
Group submission: See table V.
QUALIFICATION:
Single submission: Restricted to switch submitted.
Group submission: See table V.
Part or Identifying Number (PIN): Consists of "M" prefix followed by spec sheet number; a dash (-); and a
five-letter code. The five-letter code identifies the configuration, electrical rating, and pressure setting
mode (code from table I); high-pressure setting (coarse value code from table II) followed by fine value
with applicable tolerance (code from table III); and low-pressure setting (coarse value code from table II)
followed by fine value with applicable tolerance (code from table III). The five-letter code used in the
following example identifies a switch of configuration 1, low level to 1 ampere resistive at 28 V dc, which
actuates on increasing pressure at 1.5 ±0.5 lbf/in and deactuates on decreasing pressure at .5 ±0.5
2
2
lbf/in .
EXAMPLE:
M9395/39-
A
AJ
AG
"M" prefix and specification sheet number
Configuration, electrical, rating, and pressure setting
mode = code "A" of table I
High-pressure setting = code "A" of table II (coarse
2
value of 0 lbf/in and code "J" of table III (fine value
of 1.5 ± 0.5 lbf/in ).
2
LOW-PRESSURE SETTING = Code "A" of table II
2
(coarse value of 0 lbf/in and code "G" of table II
(fine value of 0.5 ± 0.5 lbf/in ).
2
NOTE: Design limitations (actuation values and tolerances, deadband and actuation values and
tolerances) should be coordinated with the manufacturer(s) listed on the QPL for this spec sheet before
specifying a particular "M" number. The fact that operating characteristics can be coded does not
necessarily mean that it can be manufactured or acquired.
