MIL-DTL-9395/10F
PART NUMBER: The part number shall consist of the prefix "M9395/10-" followed in turn by a character from
table I, a character from table II and a character from table III denoting the high pressure setting, and a
character from table II and a character from table III denoting the low pressure setting. Part number M9395/10-
AJKGE identifies a pressure switch of configuration 1 which actuates at 85 ±20 lbf/in2, and deactuates at
60±10 lbf/in2.
EXAMPLE:
A
J
K
G
E
M9395/10-
PREFIX.
Code character from table I denoting switch is
of configuration 1 and the setting mode is high
pressure: At, and low pressure: At.
Code character from table II denoting the high
pressure coarse setting is 80 lbf/in2.
Code character from table III denoting addition
of 5 lbf/in2 to high pressure coarse setting, and
tolerance is ±20 lbf/in2.
Code character from table II denoting the low
pressure coarse setting is 60 lbf/in2.
Code character from table III denoting addition
of 0 lbf/in2 to coarse low pressure setting, and
tolerance is ±10 lbf/in2.
TABLE I. Code character for combination of configuration and setting mode.
Code character
Pressure setting mode
High pressure: At
High pressure:
High pressure: At
Low pressure:
Differential
Configuration
Low pressure: At
Low pressure: At
Differential
1
A
B
C
2
D
E
F
3
G
H
J
4 (unused)
---
---
---
5
K
L
M
6
N
P
Q
7
R
S
T
5
